Calluna Unity Persistence

A Unity UPM package for game data persistence. Provides serialization, versioning, and migration of save data with three storage backends: PlayerPrefs, persistent data path (file-based), and SQLite.

---

SaveLoader

SaveLoader is the low-level key-value persistence interface. Use it directly when you need to save and load individual, independent values by string key.

Class hierarchy

interface SaveLoader
    class PlayerPrefsSaveLoader : SaveLoader, Injectable
    class PersistentDataPathSaveLoader : SaveLoader, Injectable, Cleanable
    class SqliteSaveLoader : SaveLoader, Injectable, Cleanable

class PlayerPrefsSaveLoaderInstaller : MonoInstaller
class PersistentDataPathSaveLoaderInstaller : MonoInstaller
class SqliteSaveLoaderInstaller : MonoInstaller

Interface

public interface SaveLoader
{
    event Action OnClear;

    bool Has(string id);
    T Load<T>(string id, T defaultValue = default);
    void Save<T>(string id, T value);
    void Delete(string id);
    void Clear();
}

PlayerPrefsSaveLoader

Stores primitives (int, float, bool, string) directly in PlayerPrefs. Complex types are JSON-serialised and stored as strings.

Use PlayerPrefsSaveLoaderInstaller to wire it. Add the MonoBehaviour to your scene's MonoContext — no further configuration is needed.

PersistentDataPathSaveLoader

Stores all data as a Dictionary<string, JToken> in a single JSON file under Application.persistentDataPath. File streams are kept open for performance and closed when Clean() is called.

Use PersistentDataPathSaveLoaderInstaller to wire it. Add the MonoBehaviour to your scene's MonoContext and set the File Name field in the Inspector (default: SaveData.txt).

SqliteSaveLoader

Stores each key-value pair as a separate row in a local SQLite database under Application.persistentDataPath. Because each key has its own row, only the rows that actually change need to be written on each save — no full-file rewrite.

Use SqliteSaveLoaderInstaller to wire it. Add the MonoBehaviour to your scene's MonoContext and configure it in the Inspector.

Inspector fields

Field	Default	Description
File Name	SaveData.db	Database file name. Must end in .db, .sqlite, .sqlite3, or .db3. If no extension is provided, .db is appended automatically.
Full Mutex	false	Opens the connection with SQLITE_OPEN_FULLMUTEX so it is safe to use from multiple threads. Enable this when using GameDataPersistence.SaveAsync().
Synchronous Off	false	Sets PRAGMA synchronous=OFF, removing WAL frame syncing. Reduces per-transaction overhead from ~2 ms to ~0.1 ms at the cost of potential data loss on OS crash or power failure. Safe on normal application exit or crash.

Bundled dependencies: the native sqlite3.dll for Windows x64 is included in Runtime/Plugins/. On macOS, Linux, iOS, and Android, the system sqlite3 library is used automatically. WebGL is not supported.

---

Usage

public class MyComponent : MonoBehaviour, Injectable
{
    private SaveLoader _saveLoader;

    public void Inject(Resolver resolver)
    {
        _saveLoader = resolver.Resolve<SaveLoader>();
    }

    void SaveData()
    {
        _saveLoader.Save("score", 9001);
        _saveLoader.Save("playerName", "Ada");
    }

    void LoadData()
    {
        int score = _saveLoader.Load("score", 0);
        string name = _saveLoader.Load("playerName", "Unknown");
    }
}

---

VersionedDataSaveLoader

VersionedDataSaveLoader wraps a SaveLoader to add automatic version-based migration for a single typed value. Use it when a single save slot needs to evolve across game versions.

Class hierarchy

class VersionedDataSaveLoader : Injectable

Public API

T Load<T>(string id, T defaultValue = default);
void Save<T>(string id, T value, int version);

• Load<T> returns defaultValue when no data is stored for the given id. When data is found it is migrated from its stored version to the current version automatically. Throws ArgumentException if no VersionedDataMigrator has been registered for T — even when no migration is needed.
• Save<T> serialises value and stores it alongside version under id.

Usage

// Save at the current version
_versionedSaveLoader.Save("myData", myValue, version: 2);

// Load — migrations from the stored version up to the current version are applied automatically
MyData loaded = _versionedSaveLoader.Load<MyData>("myData", defaultValue: new MyData());

---

VersionedDataMigrator and VersionedDataMigrationStep

VersionedDataMigrator<T> and VersionedDataMigrationStep define a sequential migration chain for a single typed value. Used exclusively with VersionedDataSaveLoader.

Class hierarchy

abstract class VersionedDataMigrator
    class VersionedDataMigrator<T> : VersionedDataMigrator

abstract class VersionedDataMigrationStep
    abstract class VersionedDataMigrationStep<TFrom, TTo> : VersionedDataMigrationStep, Injectable

Each VersionedDataMigrationStep declares its TargetVersion and converts from one data shape to the next. Steps are applied in ascending version order until the data reaches the current version. All version numbers from 1 to the highest TargetVersion must be covered — a gap throws InvalidOperationException at construction time.

A VersionedDataMigrator must be registered for every type you load via VersionedDataSaveLoader.Load<T>, even when no migration steps are needed (pass an empty or null step list in that case).

Usage

// Define migration steps
public class DataV0ToV1 : VersionedDataMigrationStep<DataV0, DataV1>
{
    public override int TargetVersion => 1;

    protected override DataV1 Migrate(DataV0 data)
    {
        return new DataV1 { Value = data.Value + 0.34f };
    }
}

public class DataV1ToV2 : VersionedDataMigrationStep<DataV1, DataV2>
{
    public override int TargetVersion => 2;

    protected override DataV2 Migrate(DataV1 data)
    {
        return new DataV2 { Value = "Data Value: " + data.Value };
    }
}

// Assemble the migrator (typically inside a MonoInstaller)
var steps = new List<VersionedDataMigrationStep>
{
    resolver.Resolve<DataV0ToV1>(),
    resolver.Resolve<DataV1ToV2>(),
};
VersionedDataMigrator migrator = new VersionedDataMigrator<DataV2>(steps);

// Bind the migrator so VersionedDataSaveLoader can pick it up
binder.Bind<IEnumerable<VersionedDataMigrator>>()
    .To<List<VersionedDataMigrator>>()
    .FromMethod(() => new List<VersionedDataMigrator> { migrator })
    .AsSingle();

---

Choosing a migration approach

	VersionedDataMigrator	GameDataMigrator
Scope	A single typed value stored under one key	The entire composite GameData blob
Use with	VersionedDataSaveLoader (low-level)	GameDataPersistence (high-level)
When to use	You are saving one independent value and it needs to evolve across versions	You are using the GameData system and need to migrate, rename, or restructure data across multiple domains simultaneously
Granularity	Per-type: each step converts TFrom → TTo	Global: receives and mutates the full Dictionary<string, JToken>

If you are using the GameData system, always use GameDataMigrator. If you are using VersionedDataSaveLoader standalone, always use VersionedDataMigrator. Do not mix them for the same data.

---

GameData System

The GameData system is the high-level persistence layer. It coordinates multiple DataSaveLoader instances, each stored under its own key in the underlying SaveLoader. The reserved key __version__ stores the current data version. Use it when your game has multiple distinct data domains that must be saved, loaded, and migrated together.

Upgrading from v1.5? The old single-blob format is automatically detected and migrated to the new per-key format on the first Load() call — no data is lost. Make sure the Game Data Id field in GameDataInstaller still matches the value you had before upgrading.

GameDataPersistence

GameDataPersistence is the main orchestrator. It coordinates load, save, version checking, and migration across all registered DataSaveLoader instances.

Class hierarchy

class GameDataPersistence : Injectable, Initializable

Public API

ReadonlyObservable<bool> LoadingFailed { get; }
ReadonlyObservable<bool> DataWasReset  { get; }

void Load();
void Save();
Task SaveAsync();
void FlushPendingWrite();
void OverrideSave(Dictionary<string, JToken> data, int version);

• Load() loads each DataSaveLoader's key individually, applies any pending GameDataMigrator steps in ascending version order, and dispatches data to each loader. If the stored version is below MinSupportedVersion all data is discarded, defaults are used, and DataWasReset is set to true. If any exception is thrown during load, LoadingFailed is set to true.
• Save() is a no-op when LoadingFailed is true. Only loaders where IsDirty == true are serialised. All dirty loaders are serialised before anything is written — if any serialisation fails the entire write is aborted, leaving storage unchanged. After a successful write, MarkClean() is called on every loader.
• SaveAsync() serialises dirty loaders on the calling (main) thread, then dispatches the write to a background thread so the caller is not blocked by I/O. Fire-and-forget is safe; await the returned Task only if you need to react to completion. Dirty flags are not cleared after an async save — the final synchronous Save() on DI cleanup handles that. Falls back to a synchronous write (with a one-time warning) when the underlying SaveLoader requires main-thread access (e.g. PlayerPrefsSaveLoader) or the platform does not support background threads (WebGL). When using SqliteSaveLoader with SaveAsync(), enable the Full Mutex toggle in SqliteSaveLoaderInstaller.
• FlushPendingWrite() blocks the calling thread until any in-progress background write started by SaveAsync() completes. Called automatically by the DI cleanup path before the final Save(), so no write is lost on scene teardown. You only need to call this manually if you are managing the DI lifecycle yourself.
• OverrideSave() writes each entry in the supplied dictionary as its own key and updates __version__; use with care. Also a no-op when LoadingFailed is true.

Usage — async saves

Call SaveAsync() from a MonoBehaviour (e.g. in response to a game event) to offload the disk write to a background thread. The Save Data On Clean path in GameDataInstaller will flush any pending write and perform a final synchronous save on scene teardown automatically.

public class AutoSaveTrigger : MonoBehaviour, Injectable
{
    private GameDataPersistence _persistence;

    public void Inject(Resolver resolver)
    {
        _persistence = resolver.Resolve<GameDataPersistence>();
    }

    // Called when the player clears a level, enters a safe zone, etc.
    public void TriggerAutoSave()
    {
        // Fire-and-forget: I/O runs on a background thread.
        _ = _persistence.SaveAsync();
    }

    // Await the Task if you need to react to completion:
    public async void TriggerAutoSaveAndShowIndicator()
    {
        await _persistence.SaveAsync();
        ShowSaveCompleteIndicator();
    }
}

SQLite + async: enable Full Mutex in SqliteSaveLoaderInstaller whenever SaveAsync() is used, so the connection is safe to access from the background write thread.

GameDataInstaller

GameDataInstaller is the scene-level MonoInstaller that wires the GameData system. Add it to your scene and configure it in the Inspector.

Inspector fields

Field	Default	Description
Game Data Id	__GameData__	The key used to detect and migrate legacy single-blob save data from v1.5 and earlier. Must match the value that was set before upgrading.
Current Version	0	The version number written on every Save().
Min Supported Version	0	Saves below this version are discarded and data is reset.
Migrators	(empty)	GameDataMigrator MonoBehaviours applied on Load().
Save Loaders	(empty)	DataSaveLoader MonoBehaviours whose data is included in the blob.
Load Data On Init	true	Automatically calls Load() during DI initialisation.
Save Data On Clean	true	Automatically calls Save() during DI cleanup.

DataSaveLoader

DataSaveLoader<TData> is the base class for per-domain save/load logic. Subclass it once per data type and register the instance in GameDataInstaller.

Class hierarchy

interface IDataSaveLoader
    abstract class DataSaveLoader : MonoBehaviour, IDataSaveLoader
        abstract class DataSaveLoader<TData> : DataSaveLoader, Injectable

Members to implement

public abstract string DataId { get; }                    // unique key within GameData
protected abstract TData GetDefaultData();                 // returned when no saved data exists
protected abstract void HandleLoadedData(TData data);      // called after deserialisation
protected abstract TData GetData();                        // called on every dirty Save()

Optional dirty tracking

By default IsDirty returns true so every Save() serialises the loader. To opt in to incremental saves, override IsDirty and MarkClean() with your own flag and set it to true whenever data changes:

public class PlayerSaveLoader : DataSaveLoader<PlayerData>
{
    private bool _isDirty = true;
    public override bool IsDirty => _isDirty;
    public override void MarkClean() => _isDirty = false;

    public int Score
    {
        get => _data.Score;
        set { _data.Score = value; _isDirty = true; }
    }
    // ...
}

Usage

public class PlayerSaveLoader : DataSaveLoader<PlayerData>
{
    public override string DataId => "player";

    protected override PlayerData GetDefaultData() => new PlayerData { Level = 1 };

    protected override void HandleLoadedData(PlayerData data)
    {
        // apply data to runtime state
        PlayerManager.Instance.ApplyData(data);
    }

    protected override PlayerData GetData()
    {
        return PlayerManager.Instance.CollectData();
    }
}

GameDataMigrator

GameDataMigrator migrates the raw composite data dictionary when the stored version is older than the current version. Subclass it, assign a Version, and register the instance in the Migrators list of GameDataInstaller. Use _serializer.SerializeToToken when writing modified values back to the dictionary. Each migrator's Version must be greater than 0 and unique — duplicates throw ArgumentException at load time.

Class hierarchy

abstract class GameDataMigrator : MonoBehaviour, Injectable

Usage

public class PlayerDataMigrator_v0Tov1 : GameDataMigrator
{
    public override int Version => 1;

    public override void Migrate(Dictionary<string, JToken> data)
    {
        PlayerData_v0 old = _serializer.Deserialize<PlayerData_v0>(data["player"]);
        PlayerData_v1 next = new PlayerData_v1 { Level = Mathf.RoundToInt(old.LevelFloat) };
        data["player"] = _serializer.SerializeToToken(next);
    }
}

Each migrator is applied only when storedVersion < migrator.Version <= currentVersion. Multiple migrators are sorted and applied in ascending version order.

---

JsonSerializer

JsonSerializer is an injectable wrapper around Newtonsoft.Json. Inject it wherever serialisation is needed instead of calling Newtonsoft directly.

Class hierarchy

class JsonSerializer : Injectable

Public API

string Serialize<T>(T value);
JToken SerializeToToken<T>(T value);
T Deserialize<T>(string stringData);
T Deserialize<T>(JToken token);

Use SerializeToToken / Deserialize<T>(JToken) when working inside GameDataMigrator or PersistentDataPathSaveLoader to avoid unnecessary string round-trips.

Customising serialisation settings

The predefined installers (PlayerPrefsSaveLoaderInstaller, PersistentDataPathSaveLoaderInstaller, GameDataInstaller) bind JsonSerializer with default settings. They do not bind JsonSerializerSettings, so if you need custom formatting, culture, or converters you must bind it yourself before the installer runs:

binder.Bind<JsonSerializerSettings>()
    .FromMethod(() => new JsonSerializerSettings { Formatting = Formatting.Indented })
    .AsSingle();

JsonSerializer resolves JsonSerializerSettings as optional — if no binding is present the defaults are used, so this step is only needed when you want to override them.

---

Editor Tooling

Game Data Viewer

An editor window for inspecting and editing raw GameData JSON stored in PlayerPrefs. Open it via Calluna > Game Data Viewer.

Features:

• Load the JSON blob from any PlayerPrefs key (defaults to __GameData__).
• Edit the text in-window and copy it to the clipboard.
• Write clipboard content back to a PlayerPrefs key.

---

ClearPlayerDataButton

ClearPlayerDataButton is a convenience MonoBehaviour that calls SaveLoader.Clear() when a UI Button is clicked. Attach it to a GameObject alongside a Button and wire the reference in the Inspector.

Class hierarchy

class ClearPlayerDataButton : MonoBehaviour, Injectable

---

Samples

The following samples are available in the Package Manager under Samples.

Sample	Description
Player Prefs Sample	Demonstrates PlayerPrefsSaveLoader and VersionedDataSaveLoader with a two-step migration chain (DataV0 -> DataV1 -> DataV2).
Persistent Data Path Sample	Demonstrates PersistentDataPathSaveLoader with file-based storage.
Game Data Sample	Demonstrates the full GameData system with multiple DataSaveLoader instances and GameDataMigrator steps.
Failed Game Data Loading Sample	Demonstrates how GameDataPersistence.LoadingFailed and DataWasReset observables behave when loading encounters an error or an unsupported version.
Observables Sample	Demonstrates subscribing to GameDataPersistence.LoadingFailed, DataWasReset, and SaveLoader.OnClear to react to persistence state changes at runtime.
SQLite Sample	Demonstrates SqliteSaveLoader as the persistence backend, including the Full Mutex and Synchronous Off Inspector settings.
