ClassVR Unity Plugin

The ClassVR Unity Plugin provides utilities and assets to enable development for ClassVR headsets and integration with ClassVR cloud services.

Installation

Unless you intend to make changes to the Plugin, please install via OpenUPM. OpenUPM installation instructions are here - https://openupm.com/packages/com.avantis.classvr/#modal-manualinstallation.

API Usage

using ClassVR;
...
// Read ClassVR headset properties
var headsetName = CVRProperties.Instance.DisplayName;

// Subscribe to new Android intents - recommended
// Note that OnIntentReceived will be called immediately if an intent is cached
IntentProvider.IntentReceived += OnIntentReceived;
...
void OnIntentReceived(AndroidIntent intent) {...}
// Read the latest Android intent - not recommended, subscribe to IntentReceived instead
var intent = IntentProvider.LatestIntent;

// Read the system locale
var sysLocale = SystemProperties.GetSysLocale();

// Send an analytics event (fire and forget)
_ = Analytics.SendEvent("example_action", "example_source");
// Send an analytics event (and wait for it to complete)
await Analytics.SendEvent("example_action", "example_source");

// Upload a small file to ClassVR Shared Cloud (on Android)
var url = await FileUploader.UploadToSharedCloud("example.txt", "text/plain", "example file contents");
// Upload a large file to ClassVR Shared Cloud (on Android)
var filePath = Path.Combine(Application.temporaryCachePath, "filename.txt");
... (write data to file)
var url = await FileUploader.UploadToSharedCloud(filePath, "text/plain");

// Retrieve a file from an Android ContentProvider
var url = "content://...";
var filePath = await ContentProviderClient.GetFile(url);

// Disable tilt to spin - note this requires the ClassVR Tilt-To-Spin OpenXR feature (see below)
var tiltToSpinFeature = OpenXRSettings.Instance.GetFeature<ClassVrTiltToSpinFeature>();
tiltToSpinFeature.EnableTiltToSpin(false);

OpenXR Integration

OpenXR Features

This plugin provides the ClassVR Tilt-To-Spin feature, which can be enabled via XR Plug-in Management. Further information on OpenXR Features can be found in the Unity OpenXR Plugin docs.

OpenXR Interaction Profiles

This plugin provides Unity support for the ClassVR 655 Headset interaction profile, which can be enabled via XR Plug-in Management. One enabled, interaction paths are available to the Unity Input System. Note that this interaction profile only includes inputs on the headset itself, for controllers please use the Oculus Touch Controller Profile.

Further information on OpenXR Interaction Profiles can be found in the Unity OpenXR Plugin docs.

ClassVR File Download/Upload

Downloads

To download files from ClassVR, use the ContentProviderClient.GetFile method with a URL of the form:

content://avnfs.com/{hash}?size={bytes}&type={mime}&name={name} (name is optional)

You can replace https:// with content:// in any AVNFS URL to use the ContentProviderClient.

This method will download the file, store it in a temporary cache directory, and return the absolute path to the file which can then be used for normal file operations.

This plugin aims to be agnostic as to which ContentProvider is being accessed, meaning you should be able to use ContentProviderClient to download files from other ContentProviders. However, this functionality has only been tested against the ClassVR AVNFS ContentProvider.

Uploads

To upload files to ClassVR, use the FileUploader.UploadToSharedCloud method. You can use any of the overloads, but for large files it's recommended to write to a temporary file and use the overload which takes a file path.

This method will assign the file to the Shared Cloud library for the organization that the device is currently registered to.

Intents and Deep Linking

To receive new intents while the app is running, direct intents to com.classvr.cvr_unity_java.DeepLinkActivity via intent filters in the manifest.

1. In your Unity player settings or build profile, Enable Custom Main Manifest under Publishing Settings
2. Open the file Assets/Plugins/Android/AndroidManifest.xml
3. Add a new activity element with attribute android:name="com.classvr.cvr_unity_java.DeepLinkActivity" and add intent filters to the activity (example below)

Example Manifest

This example shows the whole AndroidManifest.xml. You must replace the "placeholder" strings in the data elements.

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android" xmlns:tools="http://schemas.android.com/tools">
  <application>
    <activity android:name="com.unity3d.player.UnityPlayerActivity" android:theme="@style/UnityThemeSelector">
      <intent-filter>
        <action android:name="android.intent.action.MAIN" />
        <category android:name="android.intent.category.LAUNCHER" />
      </intent-filter>
      <meta-data android:name="unityplayer.UnityActivity" android:value="true" />
    </activity>
    <activity android:name="com.classvr.cvr_unity_java.DeepLinkActivity">
      <intent-filter>
        <action android:name="android.intent.action.VIEW" />
        <category android:name="android.intent.category.DEFAULT" />
        <data android:mimeType="placeholder" />
      </intent-filter>
      <intent-filter>
        <action android:name="android.intent.action.VIEW" />
        <category android:name="android.intent.category.DEFAULT" />
        <category android:name="android.intent.category.BROWSABLE" />
        <data android:scheme="placeholder" android:host="placeholder" />
      </intent-filter>
      <meta-data android:name="unityplayer.UnityActivity" android:value="true" />
    </activity>
  </application>
</manifest>
