Custom Button Unity Package

Custom Button is a flexible and extensible Unity UI Button replacement that supports color tint, sprite swap, and animation transitions for button states. Built as a Unity Package, it integrates seamlessly with the Unity Package Manager.

Features

• Color tint transition for Normal, Highlighted, Pressed, Selected, and Disabled states.
• Sprite swap transition for UI Image components.
• Animation transitions using customizable ScriptableObject presets.
• Default animation presets included: Move, Scale, Rotate, Shake, Resize, and Multi Animation.
• Support for child graphics and TextMesh Pro text color transitions.
• Easy to extend with custom animation presets.
• Sample scenes demonstrating usage.

Requirements

• Unity Editor 2023.1 (23f1) or later.
• Unity UI package (com.unity.ugui).
• TextMesh Pro (com.unity.textmeshpro).
• (Optional) Universal Render Pipeline (com.unity.render-pipelines.universal).

Installation

Clone and Open

1. Clone or download this repository.
2. In Unity Hub, click Add, then select the project folder.

As a standalone package

1. Copy the Assets/Package folder into your project's Packages directory.

2. Rename the folder to com.notask.custom-button.

3. In your project's Packages/manifest.json, add:

   "com.notask.custom-button": "file:com.notask.custom-button"


4. Save and return to Unity; the package will appear in the Package Manager.

Usage

1. Create or select a UI element with an Image component (e.g., a Button).
2. Add the CustomButton.CustomButtonClass component.
3. Assign the Target Graphic field (defaults to the Image on the GameObject).
4. Enable and configure transitions:
   • Color Tint
   • Sprite Swap
   • Animation (drag preset assets from Assets/Package/Runtime/Resources/DefaultPresets).
5. (Optional) Add sub-transitions for additional graphics or texts.

Code Example

using CustomButton;
using UnityEngine;

public class Example : MonoBehaviour
{
    public CustomButtonClass customButton;

    void Start()
    {
        customButton.onClick.AddListener(OnButtonClicked);
        customButton.onStateChange += state => Debug.Log("State changed to: " + state);
    }

    private void OnButtonClicked()
    {
        Debug.Log("Custom Button Clicked!");
    }
}

Samples

Sample scenes are included:

• Assets/Package/Samples/Overview/sample-CustomButton.unity

To import samples:

1. Open the Package Manager (Window > Package Manager).
2. Find Custom Button.
3. Click Import Samples.

Extending with Custom Presets

To create a custom animation preset:

1. In the Project window, right-click: Create > Custom Button > Presets > [PresetType].
2. Configure the preset parameters in the Inspector.
3. Assign the preset to your Custom Button component.

Contributing

Contributions are welcome. Please open issues and submit pull requests.
