MLock

A flexible and efficient lock system for Unity that manages access to gameplay elements based on configurable tags.

Overview

MLock is a powerful lock management system designed specifically for Unity that provides a structured way to control access to game objects and features. It uses a tag-based approach to determine which objects should be locked or unlocked at any given time, making it ideal for managing game state, feature access, UI interactions, and more.

Features

• Tag-based Locking: Lock and unlock objects based on customizable enum tags
• Efficient Object Pooling: Built-in object pooling for optimal performance
• Flexible API: Simple but powerful interface for integration into any project
• Inclusion/Exclusion Logic: Lock specific tags or lock everything except specific tags
• Lightweight: Minimal overhead with a focus on performance
• Generic Implementation: Works with any custom enum type for maximum flexibility
• Debug Windows: Built-in tools to monitor and control locks in real-time

Installation

# Install openupm-cli if you don't have it
npm install -g openupm-cli

# Navigate to your Unity project directory
cd path/to/your/unity/project

# Add the package
openupm add com.migsweb.mlock

{
  "scopedRegistries": [
    {
      "name": "OpenUPM",
      "url": "https://package.openupm.com",
      "scopes": [
        "com.migsweb"
      ]
    }
  ],
  "dependencies": {
    "com.migsweb.mlock": "1.2.0",
    // other dependencies...
  }
}

https://github.com/migus88/mlock.git?path=/src/mlock-unity-project/Packages/MLock#1.2.0

Quick Start

1. Define your lock tags enum (power-of-two values required as well as a zero state):

[System.Flags] // Optional
public enum GameplayFeatures
{
    None = 0, // Required
    Movement = 1 << 0,
    Inventory = 1 << 1,
    Dialog = 1 << 2,
    Combat = 1 << 3,
    // Add more as needed
}

2. Create a lock service:

using Migs.MLock;
using Migs.MLock.Interfaces;

// Create service instance (should be shared across a domain)
private ILockService<GameplayFeatures> _lockService;

void Awake()
{
    _lockService = new BaseLockService<GameplayFeatures>();
}

3. Implement the ILockable interface on objects that can be locked:

using Migs.MLock.Interfaces;
using UnityEngine;

public class PlayerController : MonoBehaviour, ILockable<GameplayFeatures>
{
    public GameplayFeatures LockTags => GameplayFeatures.Movement;

    private bool _isLocked = false;

    public void Start()
    {
        // Don't actually do that - use a proper DI framework
        GameManager.Instance.LockService.Subscribe(this);
    }

    public void OnDestroy()
    {
        GameManager.Instance.LockService.Unsubscribe(this);
    }

    public void HandleLocking()
    {
        _isLocked = true;
        // Disable movement logic here
    }

    public void HandleUnlocking()
    {
        _isLocked = false;
        // Enable movement logic here
    }

    void Update()
    {
        if (!_isLocked)
        {
            // Movement logic here
        }
    }
}

4. Create and use locks:

// Lock specific features
ILock<GameplayFeatures> movementLock = _lockService.Lock(GameplayFeatures.Movement);

// Lock everything except specific features
ILock<GameplayFeatures> lockAllButDialog = _lockService.LockAllExcept(GameplayFeatures.Dialog);

// Lock everything
ILock<GameplayFeatures> lockAll = _lockService.LockAll();

// Unlock by disposing the lock
movementLock.Dispose();

Examples

The repository includes a Car Example that demonstrates the MLock system in action. The example shows a simple car interface with menu systems where different UI elements need to be locked based on the current context. The same functionality is implemented using two different UI approaches:

Available Examples:

• Shared Components
• Car with Unity Canvas UI
• Car with UI Toolkit (UI Elements)

Advanced Usage

Using Locks with Using Statements

1. With predefined scope

// Locks are automatically disposed at the end of the block
using (_lockService.Lock(GameplayFeatures.Combat))
{
    // Combat is locked within this block
    // Run combat sequence or cutscene
}
// Combat is automatically unlocked when exiting the block

2. Until the end of the current scope

// Locks are automatically disposed at the end of the method
public void SomeComplexMethod()
{
    using var combatLock = _lockService.Lock(GameplayFeatures.Combat);

    // Do a lot of things here
    // ...
} // Combat is automatically unlocked when exiting the method

Check Lock Status

if (_lockService.IsLocked(playerController))
{
    // Player is currently locked
}

Debug Windows

MLock comes with built-in debug windows that provide real-time monitoring and control of your lock system directly within the Unity Editor.

Available Debug Windows

• Locks Debug Window: Shows all active locks, affected objects, and lock details
• Services Debug Window: Displays registered lock services and their status

Opening Debug Windows

1. In Unity, go to Window > MLock > Locks Debug or Window > MLock > Services Debug

Registering Services for Debugging

For the debug windows to work, you need to register your lock services:

// Using extension method (recommended)
var lockService = new BaseLockService<MyLockTags>().WithDebug();

// Unregister when no longer needed
lockService.WithoutDebug();

Debug Window Features

• Real-time monitoring of all active locks in your game
• Search functionality to filter locks by lockables, tags, or other criteria
• Unlock buttons to release specific locks during gameplay
• Unlock All to quickly reset all locks in the system
• Auto-refresh to keep the display updated with the latest information

Debug Window Benefits

• Troubleshooting: Quickly identify which locks are active when unexpected behavior occurs
• Development: Test locking/unlocking features without modifying code
• QA: Verify lock system behavior and relationships between game objects
• Performance Monitoring: See how many locks are active at any given time

Note: Debug windows only work in the Unity Editor and have no impact on your game builds.

Architecture

The MLock system is built around these core components:

• ILockService: Manages lockable objects and locks
• ILock: Represents a lock that can be applied to lockable objects
• ILockable: Interface for objects that can be locked
• Object Pools: Efficient reuse of lock instances for better performance

Best Practices

• Use power-of-two values for enum tags to support bitwise operations
• Dispose locks when they're no longer needed
• Consider using a dependency injection system to provide lock services
• Group related features under single tags for easier management

License

This project is licensed under the MIT License - see the LICENSE file for details.

Contact

Yuri Sokolov - GitHub
