MMVC Framework for Unity

Introduction

The MMVC (Model-Model-View-Controller) framework is a custom-designed architectural pattern for Unity, tailored to facilitate a clean separation of concerns, enhance data binding, and streamline data persistence. It's a powerful approach that blends concepts from traditional MVC and MVVM patterns to offer a reactive, scalable, and maintainable structure for your Unity projects.

At its core, the framework is built on these key principles:

• Reactive Data Binding: The ObservableVariable<T> class allows UI elements and game logic to automatically react to data changes without tight coupling.
• Separation of Concerns: Each component has a distinct responsibility: data (Model), business logic (Logic), and presentation (Presenter).
• Centralized Lifecycle Management: The Loader component acts as a central point for creating, managing, and saving/loading the other components.
• Convention over Configuration: The framework uses reflection to automatically wire up dependencies, reducing boilerplate code and simplifying setup.
• Attribute-Based Binding: Use [ObservableHandler] and [AutoBind] attributes to declaratively connect observables to handlers and UI elements.
• Automatic Component Requirements: In the Unity Editor, when you add core MMVC classes, missing dependencies are auto-added on the same GameObject (no [RequireComponent] attributes required in your concrete classes).

Core Components

The MMVC framework is comprised of four main components:

1. Model

The Model is the data layer of your application. It holds the state and is responsible for the application's data. In the MMVC framework, the Model is represented by a class that inherits from BaseObservableDataModel.

Key Features:

• It uses ObservableVariable<T> fields to store data, which automatically notify any listeners when their value changes.
• The EnsureFieldsInitialized() method automatically initializes any null ObservableVariable fields and sets up parent references for cleanup.
• Mixed Data Types: You can include regular, non-observable fields (like int, string, List<T>) alongside ObservableVariable fields in your model. The save/load system will correctly handle both.

ObservableList

For collections, the framework provides ObservableList<T>, a fully reactive list implementation.

Key Features:

• Reactivity: Similar to ObservableVariable, ObservableList notifies listeners whenever the list is modified (Add, Remove, Clear, etc.).
• Previous Value: It maintains a snapshot of the list state before the last modification, accessible via PreviousValue.
• Unity Editor Support: Fully integrated with the Unity Inspector, including undo/redo support and validation.

[Serializable]
public class InventoryModel : BaseObservableDataModel {
    // A reactive list of items
    public ObservableList<string> items = new ObservableList<string>();
}

Usage in Logic:

public void AddItem(string item) {
    GetModel().items.Add(item); // Triggers OnChanged
}

Usage in Presenter:

protected override void Start() {
    base.Start();

    // Subscribe to list changes
    GetModel().items.OnChanged.Add(OnInventoryChanged, this);
}

private void OnInventoryChanged(ObservableList<string> list) {
    Debug.Log($"Inventory updated. Count: {list.Count}");

    // Access previous state if needed
    foreach (var item in list.PreviousValue) { ... }
}

Example Model:

[Serializable]
public class PlayerDataModel : BaseObservableDataModel {
    public ObservableVariable<string> playerName;
    public ObservableVariable<int> health;
    public ObservableVariable<int> score;
    public ObservableVariable<bool> isAlive;

    // Regular fields also supported
    public List<string> achievements;
}

2. Logic

The Logic component acts as the "Controller" or "ViewModel." It contains the business logic that manipulates the Model and responds to events. It listens for changes in the Model and executes the appropriate actions.

Key Features:

• It inherits from BaseLogic<M>, where M is the type of the Model.
• Its primary role is to contain business logic that manipulates the Model.

public class PlayerLogic : BaseLogic<PlayerDataModel> {

    public void TakeDamage(int damage) {
        var health = GetModel().health.Value - damage;
        GetModel().health.Value = Mathf.Max(0, health);

        if (GetModel().health.Value <= 0) {
            GetModel().isAlive.Value = false;
        }
    }

    public void AddScore(int points) {
        GetModel().score.Value += points;
    }
}

3. Presenter Hierarchy

The framework provides two base classes for presenters, allowing you to choose the right one for your needs.

Automatic Dependency Provisioning (Editor)

The framework auto-adds required components in the Unity Editor (during Reset / OnValidate) so concrete classes no longer need explicit [RequireComponent] attributes.

Base Class	Auto-added dependency
BasePresenter<M>	M (Model)
ObservablePresenterWithLogic<M, L>	M (via base) + L (Logic)
BaseLogic<M>	M (Model)
LoaderWithModel<M>	M (Model)
LoaderWithModelAndLogic<M, L>	M (via base) + L (Logic)

This keeps setup simple: add your main class and the framework fills missing MMVC components automatically on the same GameObject in Editor mode.

BasePresenter<M>

This is the simplest presenter. It should be used when you have a Model that does not contain any ObservableVariable fields. It provides a GetModel() method but does not have any built-in reactivity.

BaseObservablePresenter<M>

This is the reactive presenter, which inherits from BasePresenter<M>. It's designed to work with a Model that uses ObservableVariable fields.

Key Features:

• It inherits from BasePresenter<M>.
• It has references to UI elements (e.g., Button, TextMeshProUGUI).
• It provides two powerful, declarative ways to handle model changes:
  • [AutoBind] attribute for simple UI bindings
  • [ObservableHandler] attribute for custom handler methods
• Automatic Setup Validation: It includes a check that will log a warning if Observable.SetListeners() was not called for it.

ObservablePresenterWithLogic<M, L>

This presenter extends BaseObservablePresenter<M> and adds a GetLogic() method for convenient access to the Logic component.

public class PlayerPresenter : ObservablePresenterWithLogic<PlayerDataModel, PlayerLogic> {

    [AutoBind("health")]
    [SerializeField] private TextMeshProUGUI healthText;

    [AutoBind("score")]
    [SerializeField] private TextMeshProUGUI scoreText;

    [ObservableHandler("isAlive")]
    private void OnIsAliveChanged(bool isAlive) {
        if (!isAlive) {
            ShowGameOverScreen();
        }
    }
}

4. Event Handling in Presenters

The framework offers two powerful, declarative approaches to handle ObservableVariable changes in your presenters. These can be used together on the same presenter.

Approach 1: AutoBind (Recommended for Simple UI Updates)

The [AutoBind] attribute provides zero-code UI binding. Simply mark a UI field with the attribute, and the framework automatically updates it when the observable value changes.

Using nameof() for Type-Safety (Recommended)

Instead of using plain string literals, use nameof() to get compile-time safety:

public class BlockDetailsPresenter : BaseObservablePresenter<BlockDetailsModalDataModel> {

    // Type-safe binding using nameof() - compile error if field is renamed
    [AutoBind(nameof(BlockDetailsModalDataModel.processingBlockExecTime))]
    [SerializeField] private Text processingBlockExecTime;

    [AutoBind(nameof(BlockDetailsModalDataModel.processingBlockFixTime))]
    [SerializeField] private Text processingBlockFixTime;
}

String Literal Binding

You can also use plain strings if you prefer:

public class GamePresenter : BaseObservablePresenter<GameDataModel> {

    // Auto-bind to model.playerScore - converts to string automatically
    [AutoBind("playerScore")]
    [SerializeField] private TextMeshProUGUI scoreText;

    // Auto-bind to model.isActive - sets Toggle.isOn
    [AutoBind("isActive")]
    [SerializeField] private Toggle activeToggle;

    // Auto-bind to model.buttonLabel - sets text on child TMP_Text
    [AutoBind("buttonLabel")]
    [SerializeField] private Button actionButton;

    // If field name matches observable name exactly, you can omit the parameter
    [AutoBind]
    [SerializeField] private TextMeshProUGUI playerName; // Binds to model.playerName
}

Supported UI Types with Built-in Adapters:

UI Type	Behavior
TextMeshProUGUI / TMP_Text	Sets text to value.ToString()
Text (Unity UI)	Sets text to value.ToString()
Toggle	Two-way binding: Sets isOn from value, and updates value when isOn changes.
TMP_InputField	Two-way binding: Sets text from value, and updates value when text changes. Supports automatic conversion for basic types (int, float, bool, etc.). Note: Complex types like Vector2 are not supported for auto-binding.
InputField (Unity UI)	Two-way binding: Sets text from value, and updates value when text changes. Supports automatic conversion for basic types (int, float, bool, etc.). Note: Complex types like Vector2 are not supported for auto-binding.
Button	Sets text on child TMP_Text component
Image	Sets sprite to Sprite value

Custom Adapters:

The framework provides two interfaces for UI adapters, following the Interface Segregation Principle:

Interface	Purpose	Methods
IUIAdapter	Display-only / Model→UI only	CanHandle(Type), Priority, SetValue(object, object, Type)
IUIListenerAdapter	Interactive / Two-way binding	Extends IUIAdapter + AddListener(object, Action<object>, Type), RemoveListener(object, object)

How to Create Custom UI Adapters

Display-Only Adapters (Model→UI)

Use IUIAdapter for components that only display data and don't need to propagate user input back to the model:

using System;
using UnityEngine;
using SavableObservable;

// Display-only adapter for a progress bar
public class ProgressBarAdapter : IUIAdapter {
    public int Priority => 100;

    public bool CanHandle(Type uiComponentType) {
        return typeof(ProgressBar).IsAssignableFrom(uiComponentType);
    }

    public void SetValue(object uiComponent, object value, Type valueType) {
        if (uiComponent is ProgressBar progressBar) {
            if (value is float floatValue) {
                progressBar.fillAmount = floatValue;
            }
        }
    }
}

Interactive Adapters (Two-Way Binding)

Use IUIListenerAdapter for components that need to propagate user input back to the model:

using System;
using UnityEngine;
using UnityEngine.UI;
using SavableObservable;

// Interactive adapter for Slider - supports two-way binding
public class SliderAdapter : IUIListenerAdapter {
    public int Priority => 100;

    public bool CanHandle(Type uiComponentType) {
        return typeof(Slider).IsAssignableFrom(uiComponentType);
    }

    public void SetValue(object uiComponent, object value, Type valueType) {
        if (uiComponent is Slider slider) {
            if (value is float floatValue)
                slider.value = floatValue;
            else if (value is int intValue)
                slider.value = intValue;
        }
    }

    // Returns an opaque token used for listener removal
    public object AddListener(object uiComponent, Action<object> onValueChanged, Type valueType) {
        if (uiComponent is Slider slider) {
            UnityAction<float> listener = val => onValueChanged(val);
            slider.onValueChanged.AddListener(listener);
            return listener; // Return the listener as the token
        }
        return null;
    }

    public void RemoveListener(object uiComponent, object token) {
        if (uiComponent is Slider slider && token is UnityAction<float> listener) {
            slider.onValueChanged.RemoveListener(listener);
        }
    }
}

Registering Custom Adapters

Register your adapters at runtime using UIAdapterRegistry.RegisterAdapter():

using SavableObservable;

public class AdapterSetup : MonoBehaviour {
    void Awake() {
        UIAdapterRegistry.RegisterAdapter(new SliderAdapter());
        UIAdapterRegistry.RegisterAdapter(new ProgressBarAdapter());
    }
}

Adapter Lookup

The registry provides two methods for adapter lookup:

• UIAdapterRegistry.GetAdapter(Type) — Returns an IUIAdapter for the given UI component type, or null if none found.
• UIAdapterRegistry.TryGetListenerAdapter(Type, out IUIListenerAdapter) — Returns true and provides an IUIListenerAdapter if the adapter supports two-way binding. Use this when you need to check if an adapter can propagate user input back to the model.

Migration Note

If you have existing custom adapters from a previous version:

1. Display-only adapters: Remove any no-op AddListener/RemoveListener implementations and implement only IUIAdapter.
2. Interactive adapters: Move listener methods into the IUIListenerAdapter interface implementation. The AddListener method now returns an opaque token (instead of void) for proper listener cleanup.

Approach 2: ObservableHandler (For Custom Logic)

When you need more than simple UI updates, use the [ObservableHandler] attribute to create dedicated handler methods.

Flexible Method Signatures:

You can define the handler method with the arguments you need. The framework will automatically provide them.

public class PlayerStatsPresenter : BaseObservablePresenter<PlayerStatsModel> {

    // Option A: No parameters - access model directly
    [ObservableHandler("level")]
    private void OnLevelChanged() {
        levelText.text = $"Level: {GetModel().level.Value}";
        PlayLevelUpAnimation();
    }

    // Option B: One parameter - receive the new value directly
    [ObservableHandler("health")]
    private void OnHealthChanged(int newHealth) {
        healthBar.fillAmount = newHealth / 100f;
    }

    // Option C: Two parameters - receive new and previous values
    [ObservableHandler("experience")]
    private void OnExperienceChanged(int current, int previous) {
        if (current > previous) {
            ShowExperienceGainPopup(current - previous);
        }
    }
}

Combining AutoBind and ObservableHandler

You can use both approaches in the same presenter. Use [AutoBind] for simple bindings and [ObservableHandler] for complex logic:

public class GameManagerPresenter : ObservablePresenterWithLogic<GameDataModel, GameLogic> {

    // Simple bindings - use AutoBind
    [AutoBind("redScore")]
    [SerializeField] private TextMeshProUGUI redScoreText;

    [AutoBind("blueScore")]
    [SerializeField] private TextMeshProUGUI blueScoreText;

    [AutoBind("statusMessage")]
    [SerializeField] private TextMeshProUGUI statusText;

    // Complex logic - use ObservableHandler
    [ObservableHandler("isGameOver")]
    private void OnGameOverChanged(bool isGameOver) {
        if (isGameOver) {
            var winner = GetLogic().DetermineWinner();
            ShowGameOverScreen(winner);
            PlayEndGameSound();
        }
    }

    [ObservableHandler("currentPlayer")]
    private void OnCurrentPlayerChanged(PlayerType player) {
        if (player == PlayerType.AI) {
            GetModel().statusMessage.Value = "AI is thinking...";
            GetLogic().StartAITurn();
        } else {
            GetModel().statusMessage.Value = "Your turn";
        }
    }
}

5. Loader (Save/Load Integration)

The framework is designed to be agnostic of any specific save/load system. Instead of providing a concrete implementation, it offers base classes that you can inherit from to easily integrate with your own save/load solution.

Base Classes

• LoaderWithModel<M>: The base class for a loader that is associated with a Model.
• LoaderWithModelAndLogic<M, LO>: Inherits from LoaderWithModel<M> and adds a GetLogic() method for convenience.

These classes provide two key methods for integration:

• public M GetModelToSave(): Call this from your save system to get the strongly-typed model component whose data you want to serialize and save.
• public virtual void LoadDataFromModel(object state): Call this from your save system after loading and deserializing data. This method applies the state to the model and crucially, sets up the reactive event listeners for the Presenter.

Example Implementation

Here is how you would create your own loader that integrates with your own save system interface (e.g., ISaveable).

1. Your Save System Interface (Example)

This is an interface from your project, not from the framework.

public interface ISaveable {
    object SaveState();
    void LoadState(object state);
}

2. Your Concrete Loader

You create a class that inherits from LoaderWithModel (or LoaderWithModelAndLogic) and also implements your ISaveable interface.

public class MyPlayerLoader : LoaderWithModel<PlayerDataModel>, ISaveable {

    // Implement the SaveState method from your ISaveable interface
    public object SaveState() {
        // Call the helper method from the framework's base class
        return GetModelToSave();
    }

    // Implement the LoadState method from your ISaveable interface
    public void LoadState(object state) {
        // Call the helper method from the framework's base class
        LoadDataFromModel(state);
    }
}

This approach gives you full control over how and when you save/load data, while the framework's base classes handle the complex work of connecting the Model and Presenter.

How to Use the Framework

Here's a step-by-step guide to implementing the MMVC framework in your Unity project:

1. Create the Model:

   • Create a new C# script that inherits from BaseObservableDataModel.
   • Add ObservableVariable<T> fields for each piece of data you want to track.

2. Create the Logic:

   • Create a new C# script that inherits from BaseLogic<YourModel>.
   • Implement methods to handle your game's business logic.

3. Create the Presenter:

   • Create a new C# script that inherits from BaseObservablePresenter<YourModel> or ObservablePresenterWithLogic<YourModel, YourLogic>.
   • Add references to your UI elements in the script.
   • Use [AutoBind] attributes for simple UI bindings.
   • Use [ObservableHandler] attributes for methods that need custom logic.

4. Create Your Loader:

   • Create a new C# script that inherits from LoaderWithModel<YourModel> or LoaderWithModelAndLogic<YourModel, YourLogic>.
   • Implement the interface of your save/load system (e.g., ISaveable).
   • In your implementation, call the GetModelToSave() and LoadDataFromModel(state) methods from the base class.

5. Set Up the GameObject:

   • In the Unity Editor, create a new GameObject.
   • Attach your Model, Logic, Presenter, and your new Loader script to the GameObject.
   • In the Inspector, connect the UI element references in your Presenter.

Usage Example

Here is a complete example of a simple component that displays a status and a timer.

1. The Model (ComponentDataModel.cs)

The model defines the data. Note that you don't need to initialize the variables; the EnsureFieldsInitialized() method in the base class will handle this automatically.

[Serializable]
public class ComponentDataModel : BaseObservableDataModel {
    public ObservableVariable<string> status;
    public ObservableVariable<bool> timerEnabled;
    public ObservableVariable<float> timerValue;
}

2. The Logic (ComponentLogic.cs)

The logic contains the methods that change the model's state.

public class ComponentLogic : BaseLogic<ComponentDataModel> {

    public void StartTimer() {
        GetModel().status.Value = "Timer Running";
        GetModel().timerEnabled.Value = true;
    }

    public void UpdateTimer(float deltaTime) {
        if (GetModel().timerEnabled.Value) {
            GetModel().timerValue.Value += deltaTime;
        }
    }
}

3. The Presenter (ComponentPresenter.cs)

The presenter uses [AutoBind] for simple bindings and [ObservableHandler] for complex logic.

public class ComponentPresenter : ObservablePresenterWithLogic<ComponentDataModel, ComponentLogic> {

    // Simple bindings - use AutoBind
    [AutoBind("status")]
    [SerializeField] private TextMeshProUGUI statusText;

    [AutoBind("timerValue")]
    [SerializeField] private TextMeshProUGUI timerText;

    // Complex logic - use ObservableHandler
    [ObservableHandler("timerEnabled")]
    private void OnTimerEnabledChanged(bool enabled) {
        // Control the visibility of a timer panel
        timerPanel.SetActive(enabled);

        if (enabled) {
            PlayTimerStartSound();
        }
    }

    [SerializeField] private GameObject timerPanel;
}

This example demonstrates the core principle of the framework: use declarative attributes to bind data to UI, keeping your presenter code clean and focused on presentation logic.

Manual Event Subscription

In addition to the automatic subscription via attributes, you can manually subscribe to the OnValueChanged event of any ObservableVariable from any class. This is useful for cross-component communication. There are two ways to subscribe: using the += operator or using the .Add() method. Each approach has different implications for memory management.

⚠️ Important: Understanding Subscription Cleanup

The framework provides automatic cleanup of subscriptions only when you use the .Add(handler, subscriber) method with a valid subscriber object. Using += creates an untracked subscription that you MUST manually unsubscribe to prevent memory leaks.

Approach 1: Using += / -= Operators (Manual Cleanup Required)

The += and -= operators provide a familiar C#-style syntax for subscribing and unsubscribing. However, this approach creates a strong reference that is NOT automatically tracked by the framework's cleanup system.

⚠️ WARNING: When using +=, you MUST manually unsubscribe using -= (typically in OnDestroy()) to prevent memory leaks. Forgetting to unsubscribe will keep your object alive in memory even after it should have been destroyed.

public class EnemyHealthMonitor : MonoBehaviour {
    [SerializeField] private PlayerDataModel playerDataModel;

    // Store the handler reference for later unsubscription
    private Action<ObservableVariable<int>> _healthHandler;

    private void Start() {
        // Create and store the handler
        _healthHandler = OnPlayerHealthChanged;

        // Subscribe using += (creates an UNTRACKED subscription)
        playerDataModel.health.OnValueChanged += _healthHandler;
    }

    private void OnDestroy() {
        // ⚠️ CRITICAL: You MUST unsubscribe manually when using +=
        // Failure to do so will cause a memory leak!
        playerDataModel.health.OnValueChanged -= _healthHandler;
    }

    private void OnPlayerHealthChanged(ObservableVariable<int> variable) {
        int newHealth = variable.Value;
        Debug.Log($"Player health is now: {newHealth}");

        if (newHealth < 30) {
            // Player is vulnerable - trigger aggressive behavior
            BecomeAggressive();
        }
    }

    private void BecomeAggressive() {
        // ... enemy behavior logic
    }
}

Approach 2: Using .Add() Method (Recommended - Auto-Cleanup Supported)

The .Add(handler, subscriber) method allows you to specify a subscriber object. When you provide a subscriber, the framework automatically tracks the subscription for cleanup when the parent data model is destroyed.

public class SomeOtherClass : MonoBehaviour {
    [SerializeField] private PlayerDataModel playerDataModel;

    private void Start() {
        // Subscribe using .Add() with 'this' as the subscriber
        // The framework tracks this subscription for automatic cleanup
        playerDataModel.health.OnValueChanged.Add(OnHealthChanged, this);
    }

    private void OnDestroy() {
        // Optional: You can manually remove if needed, but if playerDataModel
        // is destroyed, cleanup happens automatically for tracked subscriptions
        playerDataModel.health.OnValueChanged.Remove(OnHealthChanged);
    }

    private void OnHealthChanged(ObservableVariable<int> variable) {
        int newHealth = variable.Value;
        int previousHealth = variable.PreviousValue;
        Debug.Log($"Health changed from {previousHealth} to {newHealth}");
    }
}

Comparison: += vs .Add()

Feature	+= Operator	.Add(handler, subscriber)
Syntax	Familiar C# event syntax	Method call with subscriber
Auto-cleanup	❌ No	✅ Yes (when subscriber provided)
Memory leak risk	⚠️ High if you forget -=	Low
Manual unsubscribe required	✅ Always	Optional (recommended for safety)
Best for	Quick prototyping, short-lived objects	Production code, long-lived subscriptions

Best Practices

1. Prefer .Add(handler, this) for production code to benefit from automatic cleanup.
2. Always unsubscribe in OnDestroy() when using += to prevent memory leaks.
3. Store handler references if you need to unsubscribe the same handler later.
4. Consider the object lifecycle: If your subscriber might be destroyed before the data model, always use .Add() with the subscriber parameter or ensure manual cleanup.

Performance & Best Practices

Boxing and Value Types

The framework is designed to be efficient and avoid common performance pitfalls in Unity.

• No Boxing for Value Types: Because ObservableVariable<T> is a generic class, when you use it with value types (int, float, bool, Vector3, etc.), no boxing occurs when the value is set or retrieved. This prevents unnecessary memory allocations and garbage collection.
• Efficient Event Handling: The automatic subscription system uses compiled expressions or delegates, which are highly performant after the initial setup.

Memory Management and Unsubscribing

• Automatic Subscriptions: For events subscribed automatically via [AutoBind] or [ObservableHandler] attributes, the framework manages the lifetime of the subscription. You do not need to manually unsubscribe.
• Tracked Actions: The ObservableTrackedAction system automatically tracks subscriptions and cleans them up when the data model is destroyed.
• Manual Subscriptions: If you manually subscribe using OnValueChanged.Add(), the tracked action system will handle cleanup when the parent data model is destroyed.

Integrating Singletons with the MMVC Framework

This section explains how to integrate globally accessible manager classes (using a Singleton/Service Locator pattern) with your existing MMVC architecture. This pattern is ideal for central systems like a game manager, sound manager, or data store that need to be accessed from many different parts of your application without creating complex dependencies.

The approach uses a central static Services class (a Service Locator) to register and retrieve "singleton" instances that are identified by an ISharedSingleton interface.

The Core Concept: ISharedSingleton and the Services Locator

The system relies on three key parts: a marker interface, a central registry, and an initialization process.

1. The ISharedSingleton Interface

This is a simple "marker" interface. It has no methods or properties. Its sole purpose is to mark a MonoBehaviour as a global service that should be registered with the central Services registry.

namespace Assets.Scripts.Base {
    public interface ISharedSingleton {
    }
}

2. The Initialization Process (InitSingletones)

This method, which should be called once when the application starts, is responsible for finding, registering, and validating all singleton services.

Here is a breakdown of how it works:

private void InitSingletones() {
    // 1. Find all MonoBehaviours in the project, including inactive ones.
    var sharedServicesList = FindObjectsByType<MonoBehaviour>(FindObjectsInactive.Include, FindObjectsSortMode.None)
                                .AsValueEnumerable()
                                .OfType<ISharedSingleton>(); // 2. Filter for only those that implement ISharedSingleton.

    foreach (var service in sharedServicesList) {
        var mb = (MonoBehaviour)service;
        if (mb.gameObject.scene.name != null) { // 3. Ensure it's a scene object, not a prefab asset.

            // 4. Try to add the service to the central registry.
            if (Services.Add(service) != null) {

                // 5. If successful, integrate with the MMVC framework by setting up listeners.
                SavableObservable.Observable.SetListeners(service);
            } else {
                // 6. If a service of this type is already registered, enforce the Singleton pattern by quitting.
                Debug.Log($"You have more than 1 instance of {service.GetType()} with {Type.GetType(typeof(ISharedSingleton).FullName)} interface.");
                UnityEngine.Application.Quit();
#if UNITY_EDITOR
                EditorApplication.ExitPlaymode();
#endif
            }
        }
    }
}

This process creates a robust, auto-registering system for your global managers.

Step 1: Create Your Component with MMVC

First, build your component as you normally would using the MMVC pattern.

Step 2: Mark the Presenter as a Singleton

In the ComponentPresenter, implement the ISharedSingleton interface. This marks it for automatic registration on startup.

public class ComponentPresenter
    : ObservablePresenterWithLogic<ComponentDataModel, ComponentLogic>, ISharedSingleton
{
    // ... all your normal presenter code from the example above
}

Step 3: Place it in Your Scene

Ensure that the GameObject with your ComponentPresenter (and its related ComponentDataModel and ComponentLogic scripts) is present in your game's initial scene. The InitSingletones method will find and register it on startup.

Step 4: Access the Service from Other Components

Now, any other component in your project can easily access this global Component and interact with its Logic.

Example: AnotherComponent.cs

Imagine you have another MonoBehaviour in your scene. It can retrieve the ComponentLogic from the Services registry and call its methods.

using UnityEngine;

public class AnotherComponent : MonoBehaviour {

    void Start() {
        // 1. Retrieve the globally registered ComponentPresenter.
        var componentPresenter = Services.Get<ComponentPresenter>();

        if (componentPresenter != null) {
            // 2. Get its Logic component.
            var componentLogic = componentPresenter.GetLogic();

            // 3. Call a method on the Logic to change the model's state.
            // The ComponentPresenter will automatically react to this change and update its UI.
            componentLogic.StartTimer();
        }
    }
}

Conclusion

By combining the ISharedSingleton interface with a Services locator and an initialization routine, you can seamlessly integrate global manager classes into your MMVC framework. This gives you the best of both worlds:

• Decoupled Components: Individual components don't need hard references to managers.
• Centralized Access: You have a single, reliable point of access (Services.Get<T>()) for all global systems.
• Reactive Singletons: Because SetListeners is called on registered services, your global managers can fully participate in the reactive data-binding of the MMVC framework.

---

Migration from Legacy Framework

If you are migrating from an older version of this framework that used:

• Legacy typed observable classes (e.g., Observable.ObservableInt32, Observable.ObservableString)
• The OnModelValueChanged() universal handler pattern
• The InitFields() method

Please refer to the Migration Guide for detailed instructions on updating your code to the modern attribute-based system.
