Services System

A dependency injection system based on the Service Locator pattern for Unity projects. Enables centralized registration, retrieval, and initialization of services.

---

Features

• Generic service registration and retrieval
• Support for interfaces and concrete types
• Automatic service initialization
• Declarative interface mapping via GetInterfaceType()
• Service lifecycle management
• Complete unit test coverage

---

Core Components

ServiceLocator

Static container that manages service registration and retrieval.

Methods:

• Register<T>(T service) - Registers a generic service
• Register(Type type, object service) - Registers a service with specific type
• Get<T>() - Retrieves a registered service
• IsRegistered<T>() - Checks if a service is registered
• Clear() - Clears all registered services

IGameService

Base interface that all services must implement.

public interface IGameService
{
    void Initialize();
    bool IsInitialized { get; }
    Type GetInterfaceType() => GetType();
}

The GetInterfaceType() method allows each service to declare which type it should be registered as. Override to register by a custom interface.

GameServicesInitializer

MonoBehaviour component that registers and initializes all configured services during Awake().

ServiceConfig

ScriptableObject that stores the list of services to initialize. Create via Create > Game > ServiceConfig.

---

Getting Started

1. Create a Service

public interface IAudioService : IGameService

{
    void PlaySound(string soundId);
    void StopAllSounds();
}

public class AudioService : IAudioService

{
    private bool isInitialized;
    public bool IsInitialized => isInitialized;
    public Type GetInterfaceType() => typeof(IAudioService);

    public void Initialize()
    {
        isInitialized = true;
        InitializeSources();
        Debug.Log("AudioService initialized");
    }

    private void InitializeSources()
    {
        Debug.Log($"Initialize all audio sources");
    }

    public void PlaySound(string soundId)
    {
        Debug.Log($"Playing sound: {soundId}");
    }

    public void StopAllSounds()
    {
        Debug.Log("Stopping all sounds");
    }
}

2. Create ServiceConfig Asset

1. Right-click in Project panel
2. Create > Game > ServiceConfig
3. Add services to the list in the Inspector and rearrange it as needed.

3. Setup Scene

1. Create a GameObject in your scene
2. Add GameServicesInitializer component
3. Assign the ServiceConfig asset
4. Services initialize automatically on Awake()

4. Use Services

public class GameController : MonoBehaviour
{
    private void Start()
    {
        var audioService = ServiceLocator.Get<IAudioService>();
        audioService.PlaySound("background_music");
    }

    private void OnDestroy()
    {
        var audioService = ServiceLocator.Get<IAudioService>();
        audioService.StopAllSounds();
    }
}

---

Advanced Example: Multiple Services

public interface IInputService : IGameService
{
    Vector2 GetMovementInput();
}

public class InputService : IInputService
{
    public bool IsInitialized { get; private set; }

    public void Initialize()
    {
        IsInitialized = true;
    }

    public Vector2 GetMovementInput()
    {
        return new Vector2(Input.GetAxis("Horizontal"), Input.GetAxis("Vertical"));
    }

    public Type GetInterfaceType() => typeof(IInputService);
}


public interface IPhysicsService : IGameService
{
    void ApplyForce(Rigidbody rb, Vector3 force);
}

public class PhysicsService : IPhysicsService
{
    public bool IsInitialized { get; private set; }

    public void Initialize()
    {
        IsInitialized = true;
    }

    public void ApplyForce(Rigidbody rb, Vector3 force)
    {
        rb.AddForce(force, ForceMode.Force);
    }

    public Type GetInterfaceType() => typeof(IPhysicsService);
}

public class PlayerController : MonoBehaviour
{
    private IInputService inputService;
    private IPhysicsService physicsService; private Rigidbody rb;

    private void Start()
    {
        inputService = ServiceLocator.Get<IInputService>();
        physicsService = ServiceLocator.Get<IPhysicsService>();
        rb = GetComponent<Rigidbody>();
    }

    private void FixedUpdate()
    {
        var input = inputService.GetMovementInput();
        var force = new Vector3(input.x, 0, input.y) * 10f;
        physicsService.ApplyForce(rb, force);
    }
}

---

Best Practices

• Use interfaces - Always inject services through interfaces, not concrete types
• Override GetInterfaceType() - Declare the interface each service should be registered as
• Single responsibility - Each service should have one clear purpose
• Cleanup in tests - Call ServiceLocator.Clear() to prevent state pollution

---

Unit Tests

Complete test coverage included:

• ServiceLocatorTests - Service container behavior
• ServiceEntryTests - Service instantiation and caching
• GameServicesInitializerTests - Initialization flow

Run tests via Window > General > Test Runner

---

Architecture

ServicesSystem/
├── Runtime/
│   ├── ServiceLocator.cs
│   ├── IGameService.cs
│   ├── ServiceEntry.cs
│   ├── ServiceConfig.cs
│   └── GameServicesInitializer.cs
├── Editor/
│   ├── ServiceConfigEditor.cs
│   ├── ServiceConfigPreferences.cs
│   └── ServiceEntryDrawer.cs
└── Tests/
    ├── ServiceLocatorTests.cs
    ├── ServiceEntryTests.cs
    ├── GameServicesInitializerTests.cs
    └── MockGameService.cs

---

Editor Components

ServiceConfigEditor

Custom inspector for ServiceConfig asset. Provides a reorderable list interface for managing services with:

• Drag-and-drop reordering of services
• Add/remove service entries
• Visual hierarchy and property editing

ServiceEntryDrawer

Property drawer for ServiceEntry that displays a dropdown menu of all available IGameService implementations. Automatically discovers service types via reflection and allows quick selection in the inspector.

ServiceConfigPreferences

Project settings provider accessible via Edit > Project Settings > Custom Project Settings/Service Config. Enables:

• Automatic discovery of existing ServiceConfig assets
• Quick creation of new ServiceConfig if none exists
• Centralized service configuration management

---

Important Notes

• Services initialize in registration order
• ServiceLocator is static and persists across scenes (clear between levels if needed)
• Services should be thread-safe if used in multiple threads

---

Changelog

See CHANGELOG.md for version history and release notes.

Latest version 1.0.1.

---

License

This project is licensed under the GNU General Public License v3.0 - see the LICENSE file for details.

What this means

Under GPLv3, you are free to:

• Use this software for any purpose
• Modify and distribute modified versions
• Include in your projects

With the following conditions:

• Include the original license and copyright notice
• State changes made to the code
• Use the same license (GPLv3) for derivative works
• Disclose source code when distributing

For more information, visit GNU General Public License

---

Contributing

Contributions are welcome! Please feel free to submit pull requests or open issues for bugs and feature requests.
