Union struct for C#

This package provides UnionAttribute, which can be used to generate a container struct that can hold one of several specified struct types. The generated struct can also implement specified in ExposeAttribute interfaces. Key Features:

• UnionAttribute: Specifies that the container struct can hold only one of the specified struct types at a time.
• ExposeAttribute: Specifies that the container struct should implement the specified interfaces, delegating the implementation to the currently held struct.

Usage

Defining the Container Struct

Define the container struct using the UnionAttribute and ExposeAttribute attributes:

using Appegy.Union.Cells.Variants;

namespace Appegy.Union.Cells
{
    [Union(typeof(VoidCell), typeof(EmptyCell), typeof(RegularCell))]
    [Expose(typeof(IPuzzleCell), typeof(IMatchableCell), typeof(IMovableCell))]
    public partial struct PuzzleCell
    {
    }
}

Defining the Structs and Interface

Define the structs and the interface that the container struct will implement:

namespace Appegy.Union.Cells
{
    public interface IPuzzleCell
    {
        public short Id { get; }
    }

    public interface IMovableCell
    {
        public bool Movable { get; }
    }

    public interface IMatchableCell
    {
        public bool Matchable { get; }
    }
}

namespace Appegy.Union.Cells.Variants
{
    public struct VoidCell : IPuzzleCell, IMovableCell, IMatchableCell
    {
        public short Id => -2;
        public bool Movable => false;
        public bool Matchable => false;
    }

    public struct EmptyCell : IPuzzleCell, IMovableCell, IMatchableCell
    {
        public short Id => -1;
        public bool Movable => false;
        public bool Matchable => false;
    }

    public struct RegularCell : IPuzzleCell, IMovableCell, IMatchableCell
    {
        public short Id { get; set; }
        public bool Movable => true;
        public bool Matchable => true;

        public RegularCell(short id)
        {
            Id = id;
        }
    }
}

That is it. Generator will generate all necessary code.

Using the Generated PuzzleCell Struct

Creating an Array of PuzzleCell and Adding Different Cell Types

// Create an array of PuzzleCell
PuzzleCell[] puzzleCells = new PuzzleCell[3];

// Add different cell types to the array
puzzleCells[0] = new VoidCell();
puzzleCells[1] = new EmptyCell();
puzzleCells[2] = new RegularCell(42);

// Print information about the cells
foreach (var cell in puzzleCells)
{
    Debug.Log($"Type: {cell.Type}, Id: {cell.Id}, Movable: {cell.Movable}, Matchable: {cell.Matchable}");
}

Using switch to Check the Cell Type

foreach (var cell in puzzleCells)
{
    switch (cell.Type)
    {
        case PuzzleCell.Kind.VoidCell:
            Debug.Log("This is a VoidCell");
            break;
        case PuzzleCell.Kind.EmptyCell:
            Debug.Log("This is an EmptyCell");
            break;
        case PuzzleCell.Kind.RegularCell:
            Debug.Log("This is a RegularCell with Id: " + cell.Id);
            break;
        default:
            throw new ArgumentOutOfRangeException();
    }
}

Using Implicit Conversion Operators

// Implicit conversion from VoidCell to PuzzleCell
PuzzleCell voidCell = new VoidCell();

// Implicit conversion from PuzzleCell back to VoidCell
VoidCell extractedVoidCell = voidCell;

Working with Interfaces

// Create a RegularCell
PuzzleCell regularCell = new RegularCell(42);

// Use the IPuzzleCell interface
IPuzzleCell puzzleCellInterface = regularCell;
Debug.Log($"IPuzzleCell Id: {puzzleCellInterface.Id}");

// Use the IMovableCell interface
IMovableCell movableCellInterface = regularCell;
Debug.Log($"IMovableCell Movable: {movableCellInterface.Movable}");

// Use the IMatchableCell interface
IMatchableCell matchableCellInterface = regularCell;
Debug.Log($"IMatchableCell Matchable: {matchableCellInterface.Matchable}");

Debug.Log($"Extracted VoidCell Id: {extractedVoidCell.Id}");

Generated Code for UnionAttribute

// <auto-generated/>
using System;
using System.Runtime.InteropServices;
using Appegy.Union.Cells.Variants;

namespace Appegy.Union.Cells
{
    [StructLayout(LayoutKind.Explicit, Pack = 1)]
    partial struct PuzzleCell
        : IEquatable<PuzzleCell>
        , IEquatable<VoidCell>
        , IEquatable<EmptyCell>
        , IEquatable<RegularCell>
    {
        [Serializable]
        public enum Kind : byte
        {
            VoidCell,
            EmptyCell,
            RegularCell,
        }

        [FieldOffset(0)]
        private Kind _type;
        [FieldOffset(1)]
        private VoidCell _voidCell;
        [FieldOffset(1)]
        private EmptyCell _emptyCell;
        [FieldOffset(1)]
        private RegularCell _regularCell;

        public Kind Type => _type;

        public VoidCell VoidCell
        {
            get => Type != Kind.VoidCell ? throw new Exception($"Can't get VoidCell because current type is '{Type}'.") : _voidCell;
            set
            {
                _type = Kind.VoidCell;
                _voidCell = value;
            }
        }

        public EmptyCell EmptyCell
        {
            get => Type != Kind.EmptyCell ? throw new Exception($"Can't get EmptyCell because current type is '{Type}'.") : _emptyCell;
            set
            {
                _type = Kind.EmptyCell;
                _emptyCell = value;
            }
        }

        public RegularCell RegularCell
        {
            get => Type != Kind.RegularCell ? throw new Exception($"Can't get RegularCell because current type is '{Type}'.") : _regularCell;
            set
            {
                _type = Kind.RegularCell;
                _regularCell = value;
            }
        }

        public PuzzleCell(VoidCell value)
        {
            _type = Kind.VoidCell;
            _emptyCell = default;
            _regularCell = default;
            _voidCell = value;
        }

        public PuzzleCell(EmptyCell value)
        {
            _type = Kind.EmptyCell;
            _voidCell = default;
            _regularCell = default;
            _emptyCell = value;
        }

        public PuzzleCell(RegularCell value)
        {
            _type = Kind.RegularCell;
            _voidCell = default;
            _emptyCell = default;
            _regularCell = value;
        }

        public override string ToString() => _type switch
        {
            Kind.VoidCell => _voidCell.ToString(),
            Kind.EmptyCell => _emptyCell.ToString(),
            Kind.RegularCell => _regularCell.ToString(),
            _ => throw new InvalidOperationException($"Unknown type of union: {_type}")
        };

        public override int GetHashCode() => _type switch
        {
            Kind.VoidCell => _voidCell.GetHashCode(),
            Kind.EmptyCell => _emptyCell.GetHashCode(),
            Kind.RegularCell => _regularCell.GetHashCode(),
            _ => throw new InvalidOperationException($"Unknown type of union: {_type}")
        };

        public override bool Equals(object boxed) => boxed switch
        {
            PuzzleCell other => Equals(other),
            VoidCell other => Equals(other),
            EmptyCell other => Equals(other),
            RegularCell other => Equals(other),
            _ => throw new InvalidOperationException($"Unknown type of union: {_type}")
        };

        public bool Equals(PuzzleCell other) => _type == other.Type && _type switch
        {
            Kind.VoidCell => _voidCell.Equals(other.VoidCell),
            Kind.EmptyCell => _emptyCell.Equals(other.EmptyCell),
            Kind.RegularCell => _regularCell.Equals(other.RegularCell),
            _ => throw new InvalidOperationException($"Unknown type of union: {_type}")
        };

        public bool Equals(VoidCell other) => _type == Kind.VoidCell && _voidCell.Equals(other);
        public bool Equals(EmptyCell other) => _type == Kind.EmptyCell && _emptyCell.Equals(other);
        public bool Equals(RegularCell other) => _type == Kind.RegularCell && _regularCell.Equals(other);

        public static implicit operator VoidCell(PuzzleCell other) => other.VoidCell;
        public static implicit operator PuzzleCell(VoidCell other) => new PuzzleCell(other);
        public static implicit operator EmptyCell(PuzzleCell other) => other.EmptyCell;
        public static implicit operator PuzzleCell(EmptyCell other) => new PuzzleCell(other);
        public static implicit operator RegularCell(PuzzleCell other) => other.RegularCell;
        public static implicit operator PuzzleCell(RegularCell other) => new PuzzleCell(other);

        public static bool operator ==(PuzzleCell a, PuzzleCell b) => a.Equals(b);
        public static bool operator !=(PuzzleCell a, PuzzleCell b) => !a.Equals(b);
        public static bool operator ==(PuzzleCell a, VoidCell b) => a.Equals(b);
        public static bool operator !=(PuzzleCell a, VoidCell b) => !a.Equals(b);
        public static bool operator ==(PuzzleCell a, EmptyCell b) => a.Equals(b);
        public static bool operator !=(PuzzleCell a, EmptyCell b) => !a.Equals(b);
        public static bool operator ==(PuzzleCell a, RegularCell b) => a.Equals(b);
        public static bool operator !=(PuzzleCell a, RegularCell b) => !a.Equals(b);
    }
}

Generated Code for ExposeAttribute

// <auto-generated/>
using System;
using System.Runtime.InteropServices;
using Appegy.Union.Cells.Variants;
using Appegy.Union.Cells;

namespace Appegy.Union.Cells
{
    partial struct PuzzleCell :
        IPuzzleCell,
        IMatchableCell,
        IMovableCell
    {
        #region Implement IPuzzleCell

        public short Id
        {
            get
            {
                switch (_type)
                {
                    case Kind.VoidCell: return _voidCell.Id;
                    case Kind.EmptyCell: return _emptyCell.Id;
                    case Kind.RegularCell: return _regularCell.Id;
                    default: throw new InvalidOperationException($"Unknown type of union: {_type}");
                }
            }
        }

        #endregion Implement IPuzzleCell

        #region Implement IMatchableCell

        public bool Matchable
        {
            get
            {
                switch (_type)
                {
                    case Kind.VoidCell: return _voidCell.Matchable;
                    case Kind.EmptyCell: return _emptyCell.Matchable;
                    case Kind.RegularCell: return _regularCell.Matchable;
                    default: throw new InvalidOperationException($"Unknown type of union: {_type}");
                }
            }
        }

        #endregion Implement IMatchableCell

        #region Implement IMovableCell

        public bool Movable
        {
            get
            {
                switch (_type)
                {
                    case Kind.VoidCell: return _voidCell.Movable;
                    case Kind.EmptyCell: return _emptyCell.Movable;
                    case Kind.RegularCell: return _regularCell.Movable;
                    default: throw new InvalidOperationException($"Unknown type of union: {_type}");
                }
            }
        }

        #endregion Implement IMovableCell
    }
}
