Design Data Agent

Design data agent is a table parse tool for unity3D. You can define parse method easily, and parse data to unity scriptable object.

Dependencies

Import the dependencies into your project.

• Onion Data Editor : https://github.com/MacacaGames/OnionDataEditor

Usage

1. Import Design Data Agent in your unity.
2. Create a table that format is TSV.
3. Open window from menu : Window/TableParseWindow.
4. Press + button, and select the TSV table.
5. Press Execute to parse table data to target scriptable object.

Table Format

The . markers just use for format, please ignore them.

.	.	.	.
{TableDefine}	{Executable01}	{Executable02}	{Executable03}
.	{Col01Define}	{Col02Define}	{Col03Define}
ID	{Col01Name}	{Col02Name}	{Col03Name}
ID	{NameForRead}	{NameForRead}	{NameForRead}
1	{Col01Data}	{Col02Data}	{Col03Data}
...	...	...	...
999	{Col01Data}	{Col02Data}	{Col03Data}

TableDefine

{
    "title": "DataTitleInEditorWindow",
    "version": "1",
    "defaultRoot": "Assets/.../TargetScriptableObject.asset",
    "import": [],
    "locationDefine": {
        "executable":"0",
        "define":"1",
        "colName":"2",
        "dataBegin":"4"
    },
    "data": {
        "custumName01" : "data[0]"
    }
}

• title : Title display in editor window. It will help you to pick right table.
• version : Define the design data agent version. If version is too old to execute, parse window will tell you.
• defaultRoot : The target scriptable object asset path.
• import : If you have extension methods ( IDesignDataAgentMethods ), can import via the class name.
• locationDefine : Define all funcitonal row location, location start with zero.
  • executable : Is this col will execute or not. True or false.
  • define : The column define row.
  • colName : The column name row. Some method need use column name to find column.
  • dataBegin : The first data row.
• data : You can define few data to replace some value in column define. Use data by {data.NAME}.

ColDefine

{
    "methods": [ {
            "if": [
                { "name": "IsNotEmpty" }
            ],
            "do": [
                { "name": "string", "target": "{data.custumName01}.stringField" }
            ]
        }
    ],
    "onEnd": [ { ... } ]
}

Method Hooks

• methods : Default method. It will execute every column cell.
• onStart : It will execute when table parse start.
• onEnd : It will execute when table parse end.

Method Types

There are few method types can use on if/do name.

Do :

• int : Parse int and fill in target.
• float : Parse float and fill in target.
• bool : Parse bool and fill in target.
• string : Parse string and fill in target.
• object : Parse asset object and fill in target.
• Vector2 : Parse vector2 and fill in target.
• Sprite : Parse sprite and fill in target.
• enum : Parse enum and fill in target.
• Method
• ForMethod
• CreateAsset : Create asset.
• SaveAssets : Save modified assets.
• Reset : Reset target feild.
• ClearArray : Clear target array.
• Print : Print log in console.
• Invoke : Invoke method from root object.
• SetRoot : Set root object.

If :

• NotEmpty : If value is not empty, do method.
• IsEmpty : If value is empty, do method.
• IsEmptyString : If value is empty string, do method.
• IsNotEmptyString : If value is not empty string, do method.
• IsFirst : If value is the first in this column, do method.
• IsLast : If value is the last in this column, do method.
• IsExist : If the target asset exist, do method.
• IsNotExist : If the target asset doesn't exist, do method.
• IsTrue : If value is true, do method.
• IsFalse : If value is false, do method.
• IsEqual : If value equal target value, do method.
• IsNotEqual : If value doesn't equal target value, do method.

More Detail:

https://docs.google.com/spreadsheets/d/1LNIFus8uxP8Dh8NUDZGNPkYyIn05rna1rx1-T-751FI/edit?usp=sharing
