Unity SOG Plugin

A Unity UPM package that adds SOG (Spatially Ordered Gaussians) format support to Aras Pranckevičius's UnityGaussianSplatting plugin.

SOG is a compressed 3D Gaussian Splatting format by PlayCanvas that achieves ~15–20× smaller file sizes compared to PLY, using WebP images and vector quantization codebooks inside a ZIP archive.

---

Features

• Editor import — drag a .sog file into the Unity Project window; it auto-imports as a GaussianSplatAsset
• Full quality — uses Float32 buffers (no lossy re-compression)
• Higher-order SH — supports spherical harmonics up to band 3 (15 coefficients)
• Correct coordinate conversion — handles SOG's Y-down → Unity Y-up transform for positions, rotations, and SH coefficients
• Runtime loader component — SOGRuntimeLoader MonoBehaviour for assigning pre-imported assets at runtime

---

Requirements

Dependency	Version
Unity	6000.0 (Unity 6) or newer
UnityGaussianSplatting	latest
libwebp native library	1.4.0

Note: Unity's built-in ImageConversion.LoadImage does not support VP8L lossless WebP.
The editor importer requires the native libwebp.dll (see Installation).

---

Installation

Step 1 — Install UnityGaussianSplatting

In Unity Package Manager → Add package from git URL:

https://github.com/aras-p/UnityGaussianSplatting.git

Step 2 — Install this package

In Unity Package Manager → Add package from disk → select package.json from this repository.

Or add directly to your project's Packages/manifest.json:

{
  "dependencies": {
    "com.ollihuttunen.sog-gaussian-splatting": "file:../path/to/Unity-SOG_plugin"
  }
}

Step 3 — Add libwebp native library

Download libwebp 1.4.0 for Windows x64.

Extract and copy libwebp-1.4.0-windows-x64\lib\libwebp.dll to:

Packages/com.ollihuttunen.sog-gaussian-splatting/Plugins/x86_64/libwebp.dll

---

Usage

Editor Import

1. Drag a .sog file into your Unity Project window
2. Unity imports it automatically; this creates several files next to it:
   • YourFile.asset — the GaussianSplatAsset (assign this to your renderer)
   • YourFile_pos.bytes, YourFile_other.bytes, YourFile_color.bytes, YourFile_sh.bytes — binary data buffers
3. Add a GaussianSplatRenderer component to a GameObject
4. Assign the generated .asset to the renderer's Asset field

Runtime (pre-imported assets)

Add SOGRuntimeLoader to the same GameObject as GaussianSplatRenderer:

GameObject
  ├── GaussianSplatRenderer
  └── SOGRuntimeLoader
        ├── Load Source: Direct Reference
        └── Asset Reference: [drag your .asset here]

Or load from a Resources/ folder:

GameObject
  ├── GaussianSplatRenderer
  └── SOGRuntimeLoader
        ├── Load Source: Resources
        └── Resources Path: "Splats/MyScene"

---

SOG Format Overview

SOG files are ZIP archives containing:

File	Description
meta.json	Splat count, codebooks, file references
means_l.webp + means_u.webp	16-bit quantized positions (lower + upper bytes)
quats.webp	Rotations (smallest-three quaternion encoding)
scales.webp	Log-scale values via 256-entry codebook
sh0.webp	DC color coefficients + opacity
shN_centroids.webp + shN_labels.webp	Higher-order SH via two-level palette

Key technical details

Positions use a log transform:
meta.json mins/maxs are in log-space: logVal = sign(x)*log(|x|+1).
Inverse: x = sign(logVal) * (exp(|logVal|) - 1).

Quaternion component order: [qw, qx, qy, qz] (PlayCanvas internal convention).
Alpha channel in quats.webp: 252 + dropped_component_index.

Opacity: sh0.webp alpha channel is direct linear [0,1] = byte/255. Not a logit, not a codebook lookup.

Y-axis coordinate conversion (SOG Y-down → Unity Y-up):

• Position: (x, -y, z)
• Quaternion: (-qx, qy, -qz, qw) — negate qx and qz (not qy!)
• SH coefficients: negate bands with odd Y parity (sh1, sh4, sh5, sh9, sh10, sh11)

---

Project Structure

Unity-SOG_plugin/
├── package.json
├── Runtime/
│   ├── SOGData.cs              # Data structures (SOGMeta, SOGRawData, etc.)
│   ├── SOGParser.cs            # ZIP reading, WebP decoding, per-splat data extraction
│   ├── SOGConverter.cs         # SOGRawData → GaussianSplatAsset binary buffers
│   └── SOGRuntimeLoader.cs     # MonoBehaviour for runtime asset assignment
├── Editor/
│   ├── SOGImporter.cs          # ScriptedImporter (.sog → binary buffers)
│   ├── SOGImporterEditor.cs    # Custom Inspector for importer
│   ├── SOGPostprocessor.cs     # Creates GaussianSplatAsset after buffers import
│   └── LibWebPDecoder.cs       # Native libwebp P/Invoke wrapper
└── Plugins/
    └── x86_64/
        └── (place libwebp.dll here)

---

Known Limitations

• Windows x64 only (primary target) — the libwebp native plugin is configured for Windows x64. The C# code itself is fully cross-platform; only the native library needs to be swapped for other platforms.
• Editor import only — true runtime .sog loading (without prior editor import) is not yet supported. GaussianSplatAsset requires TextAsset sub-assets that can only be created in the editor.
• Unity 6+ only — uses ScriptedImporter and APIs from Unity 6.

macOS note

The plugin has not been tested on macOS but the C# code should work as-is. If you want to try it, you need libwebp.dylib instead of libwebp.dll. The easiest way to get it is via Homebrew:

brew install webp
# library location: /opt/homebrew/lib/libwebp.dylib  (Apple Silicon)
#                   /usr/local/lib/libwebp.dylib      (Intel Mac)

Place the .dylib in Plugins/macOS/ inside the package folder and configure its platform in the Unity Inspector. Contributions adding official macOS support are welcome.

---

How It Works

The import pipeline:

.sog file
  └─ SOGImporter (ScriptedImporter)
       └─ SOGParser → SOGRawData
            └─ SOGConverter → binary buffers (.bytes files)
                 └─ SOGPostprocessor → GaussianSplatAsset (.asset)
                      └─ GaussianSplatRenderer (Aras's plugin renders it)

1. SOGParser opens the ZIP, reads meta.json, decodes each WebP image using the native libwebp library, and produces SOGRawData with per-splat positions, rotations, scales, colors, and SH coefficients.
2. SOGConverter transforms the raw data into the binary buffer format expected by GaussianSplatAsset (Float32 quality, Morton-tiled color texture, 10.10.10.2 quaternion encoding).
3. SOGPostprocessor detects the generated .bytes files and assembles the final GaussianSplatAsset with all TextAsset references.

---

License

MIT License — see LICENSE file.

---

Acknowledgements

• Aras Pranckevičius for the UnityGaussianSplatting plugin
• PlayCanvas for the SOG format specification and splat-transform reference implementation
• Google WebM Project for libwebp
